- TWO TYPES OF NUT AVAILABLE PLASTIC AND METAL
- 2.1×5.5 mm DC Power Jack Socket Panel Mount (Female) comes with Metal OR PLASTIC Nut to mount the jack in your Application. It has a Plastic Cover which provides a tight connection with a male pin, Center pin can be 2.1 mm or 2.5 mm. in addition, the male plug is 2.5 mm/2.1 mm x 5.5 mm also provides good environmental protections.
- It is widely used in small-scale as well as prototyping projects where 12 to 30 Volt power supply needed such as household appliances, electric force, telecommunications, machine tool, vessel, textile, printing, Mining machine, Music Instrument, etc.
Roll over image to zoom in
DC SOCKET : NUT TYPE
- Supply voltage (V): up to 30
- Type of Connector: Female
- Supports DC Power Jack: 2.1 x 5.5 mm
- Diameter (mm): 14
- Total Length (mm): 18
- No. of Pin: 3
- Contact Resistance: ≤0.03
- Insulation Resistance (MΩ): ≥100
